Exploring GE Freezer LED Light Board: Functions and Troubleshooting

If you own a GE freezer, you may have noticed that it has a LED light board that illuminates the interior of the freezer when you open the door. But what is this light board and how does it work? And what should you do if it stops working? In this post, we will explore the functions and troubleshooting of the GE freezer LED light board.

The GE freezer LED light board is a part that holds the LED lights and controls power to them, providing bright and energy-efficient lighting for the freezer compartment.

What is the GE freezer LED light board?

The GE freezer LED light board is a part that is located behind the light lens in the freezer. It has several LED lights that are connected to a circuit board. The circuit board receives power from the main control board of the freezer and regulates the voltage to the LED lights. The LED lights are designed to last longer and use less energy than traditional incandescent bulbs.

The GE freezer LED light board is compatible with various models of GE freezers, such as GZS22IMNPHES, GSS25GGHKCBB, DSE25JSHGCSS, GSS23GGKJCBB, GSS25IGNPHBB, PSE25KGHEHWW, GSE25GGHJCBB, PZS22MSKGHSS, GSS23HGHJCBB, GSE23GGKNCCC, GSS23HMHJCES, GSS23GMKJCES, GSS25IMNPHES, GSS25IGNEHBB, GSE25GSHRCSS, GSE23GGKRCWW, DSE25JMHECES, GSS25IYNBHFS, GZS22DSJPFSS, DSE25JEMKCDS, XSS23GGKRCWW, GSE25GGHJCCC, GSE25GGHNCWW, GSE25GGHPCBB, GSE23GGKNCBB, XSS23GGKBCWW, GSE25GSHMCSS, GSS25IMNEHES and XSS25GGHNCWW.

The part number for the GE freezer LED light board is WR55X26671. You can order it online from various sources or contact GE customer service for assistance.

How to troubleshoot the GE freezer LED light board?

If your GE freezer LED light board stops working or malfunctions, you may experience some of these symptoms:

• The freezer interior is dark or dim when you open the door
• The LED lights flicker or flash intermittently
• The LED lights do not turn on or off properly
• The LED lights are too bright or too dim

To troubleshoot the GE freezer LED light board, you can try these steps:

• Check the power supply to the freezer and make sure it is plugged in securely and not tripped by a circuit breaker or fuse
• Check the door switch and make sure it is not stuck or damaged. The door switch is a part that senses when the door is opened or closed and turns on or off the LED lights accordingly
• Check the wiring and connectors between the main control board and the LED light board and make sure they are not loose or damaged
• Check the voltage to the LED light board and make sure it is within the normal range. The normal working voltage for the LED light board is 4V. The minimum support voltage is 2.6V and the maximum support voltage is 5.4V
• Check the LED lights and make sure they are not burned out or damaged. You can use a multimeter to test the continuity of each LED light

How to replace the GE freezer LED light board?

If your GE freezer LED light board is defective or damaged beyond repair, you may need to replace it with a new one. To replace the GE freezer LED light board, you will need these tools:

• A Phillips screwdriver
• A flathead screwdriver
• A pair of needle-nose pliers

To replace the GE freezer LED light board, follow these steps:

• Unplug the freezer from the power outlet and wait for at least 10 minutes to let it cool down
• Remove the shelf above the light cover and any items on it
• Remove the top screw that holds the light cover in place using a Phillips screwdriver
• Pop off the light cover by releasing the tabs on each side and on the back wall of the freezer using a flathead screwdriver
• Disconnect the wire harness from the LED light board by squeezing the tabs on each side using needle-nose pliers
• Remove the screws that secure the LED light board to the bracket using a Phillips screwdriver
• Pull out the old LED light board and discard it properly
• Align the new LED light board with the bracket and secure it with the screws using a Phillips screwdriver
• Connect the wire harness to the new LED light board by snapping it into place
• Replace the light cover by aligning the tabs with the slots and pushing it in
• Replace the top screw that holds the light cover in place using a Phillips screwdriver
• Replace the shelf and any items on it
• Plug in the freezer to the power outlet and test the LED lights

FAQs

Q: How much does a GE freezer LED light board cost?

A: The GE freezer LED light board costs around $10 to $15 depending on the source and availability. You can order it online from various websites or contact GE customer service for assistance.

Q: How long does a GE freezer LED light board last?

A: The GE freezer LED light board is designed to last longer than traditional incandescent bulbs. However, the lifespan of the LED light board may vary depending on the usage, environment and maintenance of the freezer. To extend the life of the LED light board, you should keep the freezer clean, avoid slamming the door, and replace any damaged or burned out LED lights as soon as possible.

Q: How can I find the model number of my GE freezer?

A: The model number of your GE freezer is usually located on a label inside the freezer compartment, on the left or right wall. You can also find it on your owner’s manual or receipt. The model number is a combination of letters and numbers that identifies your specific freezer model.

We hope this post has helped you understand more about the GE freezer LED light board and how to troubleshoot and replace it if needed. If you have any questions or concerns, please feel free to contact us or leave a comment below. We are always happy to help you with your kitchen appliance needs.
