How To Reset The Door Alarm On Your Kenmore Freezer

Have you ever been annoyed by the constant beeping of your Kenmore freezer’s door ajar alarm? You know, the one that tells you that your freezer door is not closed properly and your food is at risk of spoiling. You check the door, and it seems fine. You press the reset button, and nothing happens. You unplug the freezer, and plug it back in, hoping that will fix it. But no, the alarm keeps going off. What’s going on?

To reset the door ajar alarm on a Kenmore freezer, you need to press and hold the Up and Down arrows on your freezer while plugging it back in, then press and hold the Alarm Reset button for 3 seconds. This should disable the control lock and reset the alarm.

If that doesn’t work, you may have a problem with the door switch, the control board, or the sensor. In this post, we’ll show you how to troubleshoot these issues and fix them yourself. Read on to learn more!

How Does The Door Ajar Alarm Work?

The door ajar alarm is a feature that alerts you when your freezer door is not closed properly or when there is a power outage. It’s designed to prevent food spoilage and energy waste by reminding you to close the door or check the power supply.

The alarm works by sensing the position of the door switch, which is a small button that is pushed in when the door is closed and released when the door is opened. The switch sends a signal to the control board, which controls the alarm and the light inside the freezer.

When the door switch is released for more than 5 minutes, the alarm will sound and the light will flash. The alarm will stop when you close the door or press the Alarm Reset button. However, if there is a problem with the switch, the board, or the sensor, the alarm may not work properly or may go off even when the door is closed.

How To Reset The Door Ajar Alarm On A Kenmore Freezer

If your freezer’s door ajar alarm is going off for no apparent reason, you may need to reset it. There are two ways to do this:

Method 1: Press And Hold The Up And Down Arrows

This method works for most Kenmore freezers with digital displays. Here are the steps:

  • Unplug your freezer from the power outlet.
  • Press and hold the Up and Down arrows on your freezer at once while plugging it back in.
  • Press and hold your freezer’s Alarm Reset button for 3 seconds. This disables the control lock.
  • Once the control lock is off, you can press the Up arrow button thrice. This displays the 1st setting.
  • Press and hold both arrows again until you see “10” on the display.
  • Press the Alarm Reset button again to exit.

This should reset your freezer’s door ajar alarm and clear any error codes.

Method 2: Press And Hold The Alarm Reset Button

This method works for some Kenmore freezers without digital displays. Here are the steps:

  • Unplug your freezer from the power outlet.
  • Press and hold your freezer’s Alarm Reset button while plugging it back in.
  • Keep holding the button until you hear a beep or see a light flash.
  • Release the button and close the door.

This should reset your freezer’s door ajar alarm and turn off any lights.

KENMORE 795. 72063.11 SERIES SERVICE MANUAL Pdf Download | ManualsLib

What To Check If The Door Ajar Alarm Keeps Going Off

If resetting your freezer’s door ajar alarm doesn’t solve the problem, you may have a faulty component that needs to be replaced. Here are some things to check:

The Door Switch

The door switch is one of the most common causes of a malfunctioning door ajar alarm. It may be dirty, loose, or broken, preventing it from sending a correct signal to the control board.

To check the door switch, you’ll need a multimeter and a screwdriver. Here are the steps:

  • Unplug your freezer from the power outlet.
  • Locate the door switch on your freezer. It’s usually near the top hinge of the door.
  • Remove any screws or clips that hold it in place and pull it out gently.
  • Use your multimeter to test its resistance. Set it to ohms and touch its probes to each terminal of the switch.
  • Without pressing on the switch button, you should get a reading of 0 ohms or close to it. This means that it’s normally closed (NC).
  • Press on the switch button and release it several times. You should get no reading or infinite resistance when you press it, and 0 ohms when you release it. This means that it’s working properly.
  • If you get any other readings or no readings at all, your switch is faulty and needs to be replaced.

You can order a new door switch online or from a local appliance store. Make sure you get the right model for your freezer. To replace it, just reverse the steps above and plug your freezer back in.

The Control Board

The control board is the brain of your freezer. It receives signals from the door switch and other sensors and controls the alarm, the light, the temperature, and other functions. If the board is damaged or defective, it may not respond to the door switch or send incorrect signals to the alarm.

To check the control board, you’ll need a screwdriver and a flashlight. Here are the steps:

  • Unplug your freezer from the power outlet.
  • Locate the control board on your freezer. It’s usually behind a panel on the back or on the front of the freezer.
  • Remove any screws or clips that hold the panel in place and lift it off carefully.
  • Inspect the board for any signs of damage, such as burns, cracks, or corrosion. Use your flashlight to see better.
  • If you see any damage, your board is faulty and needs to be replaced.

You can order a new control board online or from a local appliance store. Make sure you get the right model for your freezer. To replace it, just reverse the steps above and plug your freezer back in.

The Sensor

The sensor is a small device that detects the temperature inside your freezer. It sends a signal to the control board, which adjusts the cooling system accordingly. If the sensor is faulty, it may send incorrect signals to the board, causing the alarm to go off.

To check the sensor, you’ll need a multimeter and a screwdriver. Here are the steps:

  • Unplug your freezer from the power outlet.
  • Locate the sensor on your freezer. It’s usually near the evaporator coils or on the side wall of the freezer.
  • Remove any screws or clips that hold it in place and pull it out gently.
  • Use your multimeter to test its resistance. Set it to ohms and touch its probes to each terminal of the sensor.
  • You should get a reading that matches the temperature inside your freezer. For example, if your freezer is at 0°F, you should get about 5K ohms. If your freezer is at 32°F, you should get about 16K ohms.
  • If you get no reading or a reading that doesn’t match the temperature, your sensor is faulty and needs to be replaced.

You can order a new sensor online or from a local appliance store. Make sure you get the right model for your freezer. To replace it, just reverse the steps above and plug your freezer back in.

sears kenmore stand up freezer

FAQs

Q: How do I know if my Kenmore freezer is working properly?

A: You can check if your Kenmore freezer is working properly by looking at its display or indicator lights. If they are on and showing normal settings, your freezer is fine. If they are off or flashing error codes, there may be a problem with your freezer.

Q: How do I prevent my Kenmore freezer’s door ajar alarm from going off?

A: You can prevent your Kenmore freezer’s door ajar alarm from going off by making sure that you close the door firmly and completely every time you use it. You can also check if there is anything blocking or preventing the door from closing properly, such as food items, ice buildup, or dirt.

Q: How do I turn off my Kenmore freezer’s door ajar alarm?

A: You can turn off your Kenmore freezer’s door ajar alarm by pressing the Alarm Reset button on your freezer. This should stop the alarm and clear any error codes. However, if there is an underlying problem with your freezer, the alarm may go off again until you fix it.

Conclusion

We hope this post has helped you learn how to reset the door ajar alarm on your Kenmore freezer and what to check if it keeps going off. By following these simple steps, you can fix this annoying problem yourself and save money on repairs.

Remember, if you need any parts for your Kenmore freezer, you can order them online or from a local appliance store. Just make sure you get the right model for your freezer.

If you found this post useful, please share it with your friends and family who may have similar issues with their freezers. And don’t forget to check out our blog for more tips and tricks on kitchen appliances and food safety!
