How To Install A New Fan In A Whirlpool Freezer And How To Test It

If you have a Whirlpool freezer that is not cooling properly, or making loud noises, you might need to replace the fan. The fan is responsible for circulating cold air inside the freezer and keeping the temperature even. Without a working fan, your food can spoil and your energy bills can go up.

But don’t worry, installing a new fan in a Whirlpool freezer is not as hard as it sounds. In fact, you can do it yourself in less than an hour with some basic tools and a little guidance. In this post, we will show you how to install a new fan in a Whirlpool freezer and how to test it to make sure it works.

What You Need To Install A New Fan In A Whirlpool Freezer

Before you start, make sure you have the following items:

• A new fan motor that is compatible with your Whirlpool freezer model. You can find the part number on the old fan motor or on the manufacturer’s website.
• A screwdriver, a nut driver, and a pair of pliers.
• A towel or a rag to protect the floor and catch any drips.
• A flashlight or a lamp to see inside the freezer.

How To Install A New Fan In A Whirlpool Freezer: Step By Step

Once you have everything ready, follow these steps to install a new fan in your Whirlpool freezer:

1. Unplug the freezer or turn off the circuit breaker that powers it. This is important for your safety and to prevent any damage to the appliance.
2. Remove the drawers and shelves from the freezer to access the back panel. You may need to lift them up and slide them out or unhook them from the rails.
3. Remove the back panel that covers the fan and the evaporator coils. Depending on your model, you may need to unscrew some screws or release some clips to do this. Be careful not to damage any wires or tubes behind the panel.
4. Unplug the fan wires from the connector or the control board. You may need to use pliers to squeeze the tabs and pull them out.
5. Remove the fan motor from its mounting bracket or panel. You may need to unscrew some screws or release some clips to do this. You may also need to remove a spring retainer from the fan blade or a washer from the motor shaft.
6. Install the new fan motor in reverse order of how you removed the old one. Make sure to transfer any rubber mounts, washers, or retainers from the old motor to the new one if needed. Connect the wires to the connector or the control board as they were before. Secure the motor to the bracket or panel with screws or clips. Slide the fan blade onto the motor shaft until it is fully seated.
7. Reinstall the back panel and secure it with screws or clips. Make sure no wires or tubes are pinched or blocked by the panel.
8. Reinstall the drawers and shelves in the freezer.
9. Plug in the freezer or turn on the circuit breaker and wait for it to start running.

How To Test The New Fan In Your Whirlpool Freezer

After installing a new fan in your Whirlpool freezer, you should test it to make sure it works properly. Here are some ways to do that:

• Listen for any unusual noises coming from the freezer. If you hear any grinding, squeaking, rattling, or humming sounds, there may be something wrong with the fan or its installation. Check if anything is loose, rubbing, or obstructing the fan blade or motor.
• Feel for any cold air coming out of the vents inside the freezer. If you don’t feel any air flow, or if it is weak or uneven, there may be something wrong with the fan or its installation. Check if anything is blocking or restricting the air circulation around the fan or the evaporator coils.
• Check for any frost build-up on the back panel or around the evaporator coils. If you see any ice forming, there may be something wrong with the defrost system or its components. The defrost system is responsible for melting any frost that accumulates on the coils and draining it away. If it fails, ice can block the air flow and prevent proper cooling.

FAQs About Installing A New Fan In A Whirlpool Freezer

Here are some common questions and answers about installing a new fan in a Whirlpool freezer:

• How do I know if I need to replace my freezer fan?
  • Some signs that your freezer fan may need to be replaced are:
    • The freezer is not cold enough or has warm spots
    • The freezer is making loud or unusual noises
    • The freezer is running constantly or cycling on and off frequently
    • The freezer has frost or ice build-up on the back panel or around the coils
• Where can I buy a new fan motor for my Whirlpool freezer?
  • You can buy a new fan motor for your Whirlpool freezer from various online or offline sources, such as:
    • The manufacturer’s website or customer service
    • An authorized dealer or service center
    • A reputable online retailer or marketplace
    • A local appliance parts store or repair shop
• How much does it cost to replace a fan motor in a Whirlpool freezer?
  • The cost to replace a fan motor in a Whirlpool freezer depends on several factors, such as:
    • The model and age of your freezer
    • The type and availability of the fan motor
    • The labor and service fees if you hire a professional
  • On average, you can expect to pay between $50 and $200 for a new fan motor and between $100 and $300 for the installation.
