If you have a Frigidaire freezer that is showing an error code H1 on the control panel, you might be wondering what it means and how to clear it. This error code means that the temperature of the freezer is too high, above 26 degrees Fahrenheit. This could be caused by a problem with the thermistor, the control board, or the door seal. The error code helps you identify and solve the issue before your food spoils or becomes unsafe to eat. In this blog post, we will explain what causes this error code and how to troubleshoot and clear it.
The main causes of the Frigidaire freezer error code H1 are:
Depending on the cause of the problem, you may be able to clear your Frigidaire freezer error code H1 by following some simple steps:
The first thing you should try is to unplug your freezer and plug it back in after 5 minutes. This may help reset the control board and clear any errors or glitches. Once you plug in your freezer, check if the error code is gone. If not, proceed to the next step.
Another reason why your Frigidaire freezer may display an error code H1 is that it is new and has not cooled down yet from the room temperature it had been stored at in the warehouse or store. It may take up to 24 hours for your freezer to reach the desired temperature after installation. To prevent this, you should avoid loading your freezer with food until it has cooled down completely. You should also make sure that your freezer is set to the correct temperature setting according to your manual.
Another possible cause of your Frigidaire freezer error code H1 is that the freezer door is open or not sealing properly. This can allow warm air to enter the freezer and raise its temperature. To prevent this, you should make sure that your freezer door is closed tightly and that nothing is blocking it from closing. You should also inspect the door seal or gasket for any cracks, tears, warps, or stains. You can also test its effectiveness by placing a sheet of paper between the door and the cabinet and closing the door. If you can pull out the paper easily, it means that the seal is loose and needs to be replaced.
Another reason why your Frigidaire freezer may show an error code H1 is that it is overloaded or poorly ventilated. This can prevent proper airflow inside the freezer and affect its cooling performance. To prevent this, you should rearrange your food items and leave some space between them and the walls of the freezer. You should also avoid placing large or tall items near the vents, which are located at the back of the freezer. You should also make sure that there is enough clearance around your freezer for proper air circulation.
Another possible cause of your Frigidaire freezer error code H1 is that the thermistor is faulty or not connected. The thermistor is a sensor that measures the temperature of the freezer and sends signals to the control board. If the thermistor is faulty or not connected, it may not sense the actual temperature of the freezer and fail to turn on the compressor when needed. To fix this, you need to check the thermistor and its wiring for any signs of damage or disconnection. You can do this by removing the lower back panel inside your freezer to access the thermistor, which is located under the air duct cover. You will need a multimeter to test the continuity of the thermistor and its wiring. If you find any problems with the thermistor or its wiring, you may need to replace them with new ones.
If none of the above steps solve your problem, you may have a defective control board that needs to be replaced. The control board is the brain of your freezer that controls all its functions and settings. If the control board is defective or corrupted, it may not receive or send proper signals to the thermistor and the compressor and cause the error code H1 to appear. To fix this, you need to replace the control board with a new one. You can do this by removing the back panel behind your freezer to access the control board, which is located at the bottom right corner. You will need to disconnect the wires and connectors from the old board and connect them to the new board. Then, you need to secure the new board in place and put back the back panel.
To prevent your Frigidaire freezer error code H1 from happening again in the future, you should follow some simple maintenance tips:
Q: How do I know if my Frigidaire freezer thermistor is bad?
A: Some signs that your Frigidaire freezer thermistor is bad are:
Q: How do I know if my Frigidaire freezer control board is bad?
A: Some signs that your Frigidaire freezer control board is bad are:
Q: How much does it cost to replace a Frigidaire freezer thermistor or control board?
A: The cost to replace a Frigidaire freezer thermistor or control board depends on the model and the availability of the parts. You can expect to pay between $10 and $50 for the thermistor and between $100 and $300 for the control board. You can also save some money by buying the parts online and replacing them yourself if you have the skills and tools.
