If you have a Frigidaire Gallery freezer that is displaying an error code 5Y EF or SY EF on the control panel, you might be wondering what it means and how to reset it. This error code indicates that there is a communication problem with the evaporator fan motor inside the freezer section. The evaporator fan motor is responsible for circulating cold air around the freezer and keeping it at the desired temperature. If the fan motor is not working properly or not communicating with the main control board, the freezer may not cool down as it should and the error code will appear. In this blog post, we will explain what causes this error code and how to troubleshoot and reset it.
The main causes of the Frigidaire Gallery freezer error code 5Y EF are:
Depending on the cause of the problem, you may be able to reset your Frigidaire Gallery freezer error code 5Y EF by following some simple steps:
The first thing you should try is to unplug your freezer and plug it back in after 5 minutes. This may help clear any errors or glitches in the control board and the fan motor. Once you plug in your freezer, open the freezer door and hold down the door switch. Listen and feel if the evaporator fan motor is running and if there is airflow inside the freezer. If the fan motor is running and there is no error code, your problem is solved. If not, proceed to the next step.
Another reason why your Frigidaire Gallery freezer may display an error code 5Y EF is that the evaporator fan motor is blocked by ice buildup on the evaporator coils. This can prevent the fan motor from spinning freely and communicating with the control board. To fix this, you need to defrost your freezer and remove any ice from the evaporator area. You can do this by removing all the food items from your freezer and taking out the lower back panel inside the freezer. You will see the evaporator coils and the fan motor above them. Use a hair dryer or a heat gun to melt any ice on the coils and the fan blades. Be careful not to damage any wires or components with excessive heat. Once you have defrosted your freezer, plug it back in and check if the error code is gone.
Another possible cause of your Frigidaire Gallery freezer error code 5Y EF is that there is a loose or damaged wiring or connector between the evaporator fan motor and the main control board. This can interrupt the communication between them and cause the error code to appear. To fix this, you need to access both the fan motor and the control board and inspect them for any signs of damage or disconnection. You can do this by removing the lower back panel inside your freezer to access the fan motor and removing the back panel behind your freezer to access the control board. You will need a multimeter to test the continuity of the wires and connectors between them. If you find any broken or loose wires or connectors, you may need to replace them with new ones.
If none of the above steps solve your problem, you may have a faulty evaporator fan motor or a defective main control board that needs to be replaced. You can test the fan motor by using a multimeter to check if it is getting power from the control board. If there is power but no movement, you may need to replace the fan motor with a new one. You can also test the control board by using a multimeter to check if it is sending power to the fan motor. If there is no power or if there are any signs of damage or corrosion on the board, you may need to replace the control board with a new one.
To prevent your Frigidaire Gallery freezer error code 5Y EF from happening again in the future, you should follow some simple maintenance tips:
Q: How do I know if my Frigidaire Gallery freezer evaporator fan motor is bad?
A: Some signs that your Frigidaire Gallery freezer evaporator fan motor is bad are:
Q: How do I know if my Frigidaire Gallery freezer main control board is bad?
A: Some signs that your Frigidaire Gallery freezer main control board is bad are:
Q: How much does it cost to replace a Frigidaire Gallery freezer evaporator fan motor or main control board?
A: The cost to replace a Frigidaire Gallery freezer evaporator fan motor or main control board depends on the model and the availability of the parts. You can expect to pay between $50 and $200 for the parts and between $100 and $300 for the labor. You can also save some money by buying the parts online and replacing them yourself if you have the skills and tools.
