Kenmore Elite Refrigerator Bottom Freezer Door – How To Detach and Reattach

If you need to move, clean, or repair your Kenmore Elite refrigerator, you may need to remove and reattach the bottom freezer door. This may seem like a daunting task, but it’s actually not that hard if you follow the right steps and have the right tools. In this blog post, we’ll show you how to remove and reattach the bottom freezer door on your Kenmore Elite refrigerator safely and easily.

To remove and reattach the bottom freezer door on your Kenmore Elite refrigerator, you need to disconnect the water supply line, remove the hinge cover and screws, lift off the door, and reverse the process to reattach it. You also need to remove and reattach the door handle and the bottom drawer.

What you’ll need

Before you start, make sure you have the following tools and materials:

• A Phillips screwdriver
• A flat-blade screwdriver
• A pair of pliers
• A bucket or a basin
• A towel or a rag

How to remove the bottom freezer door

To remove the bottom freezer door on your Kenmore Elite refrigerator, follow these steps:

1. Unplug your refrigerator from the power outlet or turn off the circuit breaker that controls it. This will prevent any electrical accidents while you work on your refrigerator.
2. Remove the water supply line from the left door. To do this, locate the connector on the line behind the toe grille at the bottom of your refrigerator. Press the ring on the connector to release the line and pull it out of the connector. Place the end of the line in a bucket or a basin to catch any water that may drip from it.
3. Remove the hinge cover and screws from the top of the left door. To do this, open the left door and use a Phillips screwdriver to unscrew the screw that holds the hinge cover in place. Lift off the hinge cover and set it aside. Then, use a Phillips screwdriver to unscrew the three screws that secure the top hinge to the cabinet. Set them aside as well.
4. Lift off the left door from the bottom hinge. To do this, hold the door by both sides and lift it up slightly to free it from the bottom hinge pin. Be careful not to damage or disconnect any wires or tubes that run through the hinge. Set the door aside on a towel or a rag to protect it from scratches.
5. Repeat steps 2 to 4 for the right door if you need to remove it as well.

How to reattach the bottom freezer door

To reattach the bottom freezer door on your Kenmore Elite refrigerator, follow these steps:

1. Align the left door with the bottom hinge pin and lower it into place. Make sure that any wires or tubes that run through the hinge are not pinched or damaged.
2. Reattach the top hinge and screws to the cabinet. To do this, align the holes on the top hinge with those on the cabinet and use a Phillips screwdriver to screw in the three screws that secure them together.
3. Reattach the hinge cover and screw to the top of the left door. To do this, align the tabs on the hinge cover with those on the top hinge and snap them into place. Then, use a Phillips screwdriver to screw in the screw that holds them together.
4. Reconnect the water supply line to the left door. To do this, locate the connector on the line behind the toe grille at the bottom of your refrigerator. Push the line into the connector until it clicks into place.
5. Repeat steps 1 to 4 for the right door if you removed it as well.

How to remove and reattach

the door handle

To remove and reattach the door handle on your Kenmore Elite refrigerator, follow these steps:

1. Disconnect the unit from electric power and open the door of the refrigerator.
2. Find the screws securing the top of the handle to the door. Unmount them and set them aside carefully.
3. Move the handle away from the corner guard. Then, slide it down until it comes off the lower mounting bracket. Set it aside as well.
4. To reattach the handle, reverse the process. Slide it up onto the lower mounting bracket until it locks into place. Then, align it with the corner guard and secure it with the screws.

How to remove and reattach

the bottom drawer

To remove and reattach the bottom drawer on your Kenmore Elite refrigerator, follow these steps:

1. Pull out the drawer to its full extension.
2. Go to the rail on the left and with a flat-blade screwdriver, push the tab in order to loosen the drawer and detach it from the rail.
3. Next, go to the right side of the drawer and push the tab there to loosen the drawer.
4. Lift and remove the drawer from the refrigerator.
5. To reattach the drawer, reverse the process. Align it with the rails and slide it in until it clicks into place.

FAQs about removing and reattaching the bottom freezer door

Here are some common questions and answers about removing and reattaching the bottom freezer door on your Kenmore Elite refrigerator that you may find helpful:

• Why do I need to remove and reattach the bottom freezer door? You may need to remove and reattach the bottom freezer door for various reasons, such as:
  • Moving your refrigerator to a new location or fitting it through a narrow doorway
  • Cleaning your refrigerator thoroughly or removing any spills or stains from the door
  • Repairing or replacing any parts or components of your refrigerator or the door
• What are the benefits of removing and reattaching the bottom freezer door? Removing and reattaching the bottom freezer door can have several benefits, such as:
  • Saving time and money by doing it yourself instead of hiring a professional
  • Improving the appearance and hygiene of your refrigerator by removing any dirt or debris from the door
  • Enhancing the performance and efficiency of your refrigerator by fixing any issues or problems with the door
• What are some tips for removing and reattaching the bottom freezer door? Here are some tips for removing and reattaching the bottom freezer door safely and effectively:
  • Read and follow the owner’s manual for more specific instructions and precautions for your model of refrigerator
  • Wear gloves and protective eyewear to avoid any injuries from sharp edges or metal parts
  • Have a helper to assist you with lifting and holding the door, especially if it’s heavy or large
  • Use a towel or a rag to protect the floor and the door from scratches or dents

Conclusion

Removing and reattaching the bottom freezer door on your Kenmore Elite refrigerator is an easy way to maintain and improve your appliance. By following these simple steps, you can remove and reattach the bottom freezer door in no time and enjoy the benefits of having a clean and efficient refrigerator.
